Deepcool PM750D 80 Plus Gold SMPS

DeepCool
Availability:

Out of stock


  • 80 PLUS Gold certified lower power consumption, 850 Watt, Non- Modular
  • 100000 Hours MTBF, Support ATX12V V2.4
  • Topology : Active PFC + Full Bridge SRC LLC + DC to DC
  • Product Dimensions – 150×140×86mm (W x L x H)
  • 5 Year Warranty

6,200 6,510

Out of stock

DeepCool PM750D

Series non-modular power supplies are certified 80 PLUS Gold for efficient power delivery with great performance at a great value.

80 PLUS GOLD CERTIFIED

Guarantees a minimum efficiency of 90% or higher under typical loads for reliable power delivery with little waste.

QUALITY TOPOLOG

For solid power performance and minimal signal noise, the PM-D series PSU features a full-bridge LLC topology with DC-DC conversion and Japanese bulk capacitors that delivers terrific reliability.

BUILT TO SPEC

Made to meet modern power supply design standards for consistent voltage stability, each PM-D power supply is also compliant with Intel PSU guidelines that support instant-on power from sleep or standby modes.80 PLUS® Gold80 PLUS® Gold certified – Up to 87~90% efficient (20~100% Loading)Silent and High Performance Fan120mm silent fan has temperature control function to keep low noise

ENOUGH POWER TO GO AROUND

The PM750D features three independent PCIe outputs and two EPS connectors for continuous high quality power that supports the latest high-end graphics cards and motherboards for gaming excellence.

EFFICIENCY THROUGHOUT

The PM-D series power supplies are compliant with the 2014 ErP regulations on energy savings and also the IEC 62368-1 for safety standards.

PEACE OF MIND

Safeguard your power source with well-round circuit protection including OPP/OVP/SCP/OTP/OCP.

Weight 1.5 kg
Dimensions 6.5 × 6 × 4 in
Brands

Specifications

Type ATX12V V2.4
Product Dimensions 150×140×86mm (W x L x H)
80PLUS Certifications GOLD
Fan Size 120mm
Fan Bearing Hypro Bearing
Topology Active PFC + Full Bridge SRC LLC + DC to DC
Capacitors Japanese Bulk Capacitor
Power Good Signal 100-150ms
Hold Up Time ≥16ms(75% Load)
Efficiency ≥90% Under Typical Load(50% Loading)
Protection OPP/OVP/SCP/OTP/OCP
Operation Temperature 0-40°C
Regulatory TUV/cTUVus/CCC/CE/FCC/UKCA/EAC/BIS
Erp Regulation ErP(2014)
MTBF 100,000 Hours
Warranty 5 Years
Note *** Features, Price, Specifications are subject to change without notice.
